Lincat Opus 800 OE8802 Electric Bratt Pan (DISCONTINUED)

• 3 x 4kW stainless steel heating elements
• Temperature range from 70°C to 300°C to meet different cooking needs and for maximum flexibility
• Simmer mode reduces power to 50% for delicate dishes
• Manually operated tilting mechanism
• Fold away handle

• Heavy duty lid and hinge system
• 2mm thick stainless steel lid doubles as a bench-top workspace
• Water fill tap with latching push button can be operated when lid is open or closed
• Large pouring spout and lip to avoid the risk of spillage

• Dimensions: 1000(H) x 900(W) x 800(D)mm
• Pan dimensions: 820(W) x 500(D)mm
• Total power: 12kW - 3 Phase
• Pan capacity: 80 Litre
• Temperature range from 70°C to 300°C
• Net weight: 190 KG
• Packed weight: 204 KG

Why should I buy the OE8802?

Bratt pans have been designed and developed specifically for heavy duty use in large scale food production - preparing say, the ultimate curry or the richest bolognese for 100 people. This tilting bratt pan, the OE8802 from Lincat’s new Opus 800 series, is an electric unit with a total power rating of 12kW from 3 x 4kW stainless steel heating elements. It has a large capacity of 80 litres. The temperature range is thermostatically controlled from 70°C to 300°C - this wide range can comfortably accommodate different cooking processes for maximum flexibility. A simmer mode reduces heat by 50% for more delicate dishes.

This is a heavy duty commercial cooking appliance for high output food production environments, most often found in hospitals, schools, factory and staff canteens and similar institutions and businesses such as large banqueting operations. Lincat provide a comprehensive 2 year on site UK parts and labour warranty on this product.

Bratt pans are highly versatile and will perform many different cooking operations including braising, roasting, boiling, poaching, steaming or stewing. Menu options for customers and/or staff don’t need to be limited - they can be as varied as chef’s imagination. This single appliance can replace a variety of kitchen pots and pans as well as sole-function cooking equipment, creating space in working kitchens. Commercially, they are a sound investment.

The overall dimensions of the bratt pan are 900mm(h) x 900mm(w) x 800mm(d) and it has a net weight of 190 kilos with a packed weight of 204 kilos. It is fitted with lockable castors as standard; in the case of uneven flooring height adjustable legs are available as an option. The 800mm depth is uniform throughout the Opus 800 series of equipment. The unit is constructed from a fully framed 2mm thick steel chassis and stainless steel panels in thicknesses up to 2mm. There are permanent laser etched markings on control knobs and fascia. There are direct connections for water supply and waste; the bratt pan requires a 3 phase electrical supply to be installed by a qualified electrician.

The pan itself has dimensions of 820mm x 500mm; the depth of the pan is 200mm. The pan base is 8mm thick for improved heat retention and even heat distribution. The hinged and spring balanced lid - which is designed to contain condensation - is robust and manufactured from stainless steel; it cleverly doubles as a bench-top workspace. The tilting mechanism makes dispensing food - and cleaning afterwards - so much easier; it is manually operated. The power and water fill system are automatically disconnected when the tilt mechanism is activated.

The water fill tap with latching push button can be used when the lid is open or closed. There is a large pouring spout and lip to avoid the risk of spillages. Together with their versatility, Bratt pans are labour saving, in cooking times and cleaning tasks: the appliance is easy to clean with a high sheen stainless steel finish; the tank is unobstructed and easy to access.

This tough, durable and large capacity tilting bratt pan is also available in natural and propane gas models.
